C5 Combifloat JU Modular Pontoon 18m x 12m DECK LOAD 80t

GENERAL
Type C5-110Modular Self Elevation Platform
Classification Combifloat Pontoons C5

VESSEL PARTICULARS
Length 18.3m
Breadth 12m
Height 1.52m
Deck Load 15T /M2
Available Deck Area 200m2
Leg Length 18m OR 27m
Leg Diameter (OD) 0.762mm
Moonpool 1No x 330mm Approx
Deck Lift Capacity 80T

WEIGHTS
Pontoon Weight (Each) 13.1T
Duofloat 13.8T (2 No) or 6.9T Each
Jacking Units (Each) 5T
Leg (Each) 15.7T (Full Sections)

OCM DECK EQUIPMENT
Power Pack Deutz F6L912 Air-cooled
Canteen & Workshop 20T Container
Hand Railings Vessel Perimeter
Day Shapes Yes
Access Ladder Vertical
Gangway Yes/Available

ADDITIONAL INFORMATION
No of Truck Movements 7No (5No 40ft & 2 No 6ft)
