C7 Combifloat JU Modular Pontoon 30.5m x 18.5m DECK LOAD 400t

GENERAL
Type C7-400 Modular Self Elevation
Platform Classification Combifloat Pontoons C7

VESSEL PARTICULARS
Length 24m 30m
Breadth 18m 18m
Height 2.1m 2.1m
Deck Load 15T/M2 400T
Available Deck Area 432m2
Leg Length 12m and 18m Sections = 30m 48.5m
Leg Diameter (OD) 1.1m
Moonpool Optional

WEIGHTS
Pontoon Weight ( Each) 17T
Jacking Units (Each) 25T
Leg ( Each) 12T and 18T Sections = 30T

OCM DECK EQUIPMENT
Power Pack 2No Deutz F6L912 Air-cooled
Canteen & Workshop 20T Container
Hand Railings Vessel Perimeter
Day Shapes Yes
Navigation lights Yes
Mooring Winches 4No 15T Winches, Fairleads & Roller
Access Ladder Vertical
Gangway Yes / Available

OTHER INFORMATION
No Of Truck Movements 29 No
